Description

Consistent performance in demanding conditions

Ensure a secure and reliable electrical connection in even the harshest environments. Designed for marine, industrial, outdoor, automotive and other demanding applications, this IP67 Waterproof Circular Line Socket is built to withstand tough conditions. With an IP67 waterproof rating, this socket provides protection against dust and water ingress, making it ideal for use in challenging environments. Operating within a wide temperature range of -40°C to 105°C, this socket is suitable for a variety of applications.
IP67 Waterproof Circular Line Socket Features:

• IP67 rated
• Locking bayonet connection
• UL rated
• Wide temperature: -40°C to 105°C
• Solder pins
• 2-Pin versions rated to 5A
• 4-Pin and 6-pin versions rated to 2A

IP67 Waterproof 2-Pin Circular Line Socket Specifications:

• DC current rating: 5A (2 Pin), 2A (4 and 6 Pin)
• Socket type: LTW Round Size C
• Contacts/pins: 2, 4, 6
• Attachment method : Solder tag
• Case material: Plastic
• Contact material: Gold plated
